Ajax MotionCam white
10010309
AX Kameradetektor (Hvit)
MotionCam simultaneously uses two specialized radio protocols: Jeweller for sending instantaneous alarms and Wings for rapid image delivery
You’ll receive the first snapshot of the event within 9 seconds after motion is detected
As usual, the alarm notification will arrive in a split of a second, even if the signal is unstable
You can set up MotionCam at a distance of up to 1700 meters from the hub to establish visual control of the most critical areas
The new detector features a record-breaking operating efficiency with up to 4 years of battery life
Smart motion detection
Visual alarm verificationTech specs
Classification - Electro-optical combined radio channel security detector with a photo camera
Detector type - Wireless
Installation - Indoors
Motion detection distance - Up to 12 m
Pet immunity - Weight: up to 20 kg / Height: up to 50 cm
Compatibility - Only with Hub 2, Hub 2 Plus
Sensing element - PIR sensor
Detection angles - Horizontal — 88.5° / Vertical — 80°
Time for motion detection - From 0.3 to 2 m/s
Camera view angle - 90°
Alarm signal delivery time - 0.15 sec
Photo verification - Time to deliver a photograph with default settings: up to 9 sec
Photo quality: up to 640 × 480
Pictures in a series: 1-5 pcs
IR backlight for night mode pictures - Available
Sensitivity - Adjustable, 3 levels
Recommended installation height - 2.4 m
Power supply - Batteries: CR123A (×2), 3 V
Battery life - Up to 4 years (up to 2.5 years if “Delay when entering” setting is activated)
Jeweller radio technology
Communication range with detectors: up to 1,700 m in the line of sight
Two-way communication between devices
Operating frequencies: 868.0 - 868.6 MHz
Self-adjusting RF output power: up to 20 mW
Block encryption based on AES algorithm
Detector polling period: 12−300 s
Frequency hopping
Wings radio technology - Transmission of visual alarm verifications
Temperature sensor - Available
Operating temperature range:
From 0°C to +40°C (manufacture date up to June 1, 2020)
From -10°C to +40°C (manufacture date from June 1, 2020)
Operating humidity - Up to 75%
Anti-sabotage
Fraud protection
Jamming notification
Tamper-resistant
CMS compatibility
CMS connectivity: Contact ID, SIA (DC-09)
CMS software supporting visual alarms verification
Remote configuration and testing
Protection class - IP50
Dimensions - 135 × 70 × 60 mm
Weight - 167 g
Warranty - Replacement and repair for a period of 24 months from the date of sale. The warranty does not cover batteries
Complete Set:
MotionCam motion detector
SmartBracket mounting panel
x2 CR123A batteries (pre-installed)
Installation kit
Quick Start Guide
Service life - 10 years
| Category | Alarm |
|---|---|
| Sub-category | Ajax |
| Brand | Ajax |
| Alarm Type | Motion detection |
| Color | Hvit |
