Ajax Button black
10010314
AX Trykk-knapp 1-Knapp (Svart)
Guarantees alarm delivery
Ajax panic button communicates with a hub using Jeweller radio protocol on a distance of up to 1300 m. Once it delivers an alarm, you’ll see a green blink
Jeweller encrypts all of the transmitted data. In case of signal interference or radio jamming, Ajax system switches the radio frequency and notifies you as well as the security company about the situation.
- Signal range up to 1300 m
- Command delivery confirmation
- Encryption with a modified AES algorithm
- Frequency hopping
Two modes: panic/control button
Protected from accidental activation
Protected from dust and splashesTech specs
Classification - Addressed Radio Panic Button
Compatibility - Operates with all Ajax hubs, and range extenders
False alarm prevention -Yes (in the Panic mode)
Number of buttons - 1
Alarm transmission - Not longer than 0,15 sec
Active from the first click (no need to wake it up)
Adjustable alarm types - Intrusion,Fire,Medical help,Panic button,Gas leak
Jeweller radio technology - Communication range with a hub — up to 1300 m in an open area:
Two-way communication channel
Operating frequencies — 868.0 - 868.6 MHz
Self-adjusting RF output power — up to 20 mW
Block encryption based on AES algorithm
Frequency hopping
Power supply - Battery: CR2032 battery, 3 V
Battery life - Up to 5 years
Operating temperature range - From -10°C to +40°C
Permissible humidity - Up to 75%
Protection class - IP55
Size - 47 × 35 × 13 mm
Weight - 16 g
Warranty - Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty
Complete set:
Panic button
Pre-installed CR2032 battery
Double sided tape
Quick Start Guide
Service life - 10 years
| Category | Alarm |
|---|---|
| Sub-category | Ajax |
| Brand | Ajax |
| Alarm Type | Keypads and arming devices |
| Color | Svart |
